Wall Mounted Flexible Power Distribution

Starline Plug-In Raceway has the unique ability to add or relocate plug-in modules anywhere on the raceway quickly and easily – making it the perfect solution to meet the ever-changing power distribution and datacom needs of research/ pharmaceutical/ university labs, offices, hospitals, retail and data centers.

Starline’s innovative, reconfigurable design eliminates the added cost of an electrician to reconfigure circuits, receptacles and wiring. With Plug-In Raceway, you have the advantage of arranging your electrical outlets based upon the needs of your workspace, not arranging your workspace based around your electrical outlets. In addition, you also have the freedom to move around equipment or change a workflow layout without having to worry about having a connection to power.

Starline Plug-In Raceway not only offers flexibility and low cost of ownership, but additional benefits:

  • Reliability – Starline Plug-In Raceway has been tested to meet NEC, IEC and UL standards and has the ETL mark. Joints and plug-in units require no maintenance.
  • Aesthetically appealing – the electrical raceway is built with a smooth aluminum finish and its compact design requires minimal space. Starline Plug-In Raceway is available in white, metallic silver, or custom colors are also available.
  • Reduced Installation Costs – Starline Plug-In Raceway makes installation quick and easy, and lowers the costs because it takes about one third less time to install so labor costs are cut dramatically. Also, the modules are so easy to install, that an electrician is not needed.
  • Safety and Convenience – Starline Plug-In Raceway allows the user to avoid large panel boards in a remote location and has greater flexibility without the confusion of determining what breaker corresponds to which outlet.

Features:

  • Available in 20, 40 or 60 amps bussing; 120V or 240V; 5 wire.
  • Customizable lengths of raceway sections up to 10ft.
  • Optional Isolated Ground
  • Various plug-in modules are available complete with breaker and receptacle, and can be relocated anywhere on the raceway quickly and easily.
  • Plug-in modules are available in single phase and three phase configurations up to 30 amps.
  • A variety of power feeds, elbows and fittings are available.
  • Optional datacom channel is available for data, video and audio applications.





Underfloor Flexible Power Distribution

Legrand’s Electrak, is a leading name in power distribution and lighting control solutions.

Electrak Powertrack or underfloor busbar is perfect for cavity floor installations. With minimal parts, push-fit assembly and a complementary range of floor boxes and grommets, this flexible, easy-to-install system can be reconfigured as office layouts evolve.

The system consists of continuous lengths of track which are fed via a feed unit and can be installed in floor voids as low as 48mm.

Features:

  • 63 A rated, IP 40 protection
  • Available in five versions: single phase, clean earth, dual circuit, three phase and auxiliary earth
  • Available in 1.2m, 1.8m, 2.4m and 3.6m lengths
  • Tap-off outlets are located at every 300 or 600mm pitch
  • Floor mountable (stand-off brackets also available)



Floor Boxes

Electrak two, three and four compartment raised access floor boxes and slab boxes offer complete versatility. Floor boxes are available pre-wired with Powertrack tap-off, or supplied empty (unassembled), with a choice of single or separate compartment bases and three depth options. With a vast selection of power and data plates available, boxes can be tailored to the specific requirements of each office installation.

Floor Grommets

Simple to install, the Electrak range of floor grommets is available from 144mm to 232mm in diameter and allow cables and conduit to link between underfloor power and desk power systems.
